ZG. XZSD2-800 x 20 automatic disc turquoise vertical injection molding machine

Times:       Date:12-10-09
ZG. XZSD2-800 x 20 automatic disc turquoise vertical injection molding machine

performance characteristics
1 microcomputer control technology, to achieve full control of the machine working condition, with automatic fault alarm function can.
2 "touch" the man-machine interface, so that each set of operating parameters and to achieve a comprehensive and intuitive.
3 high-speed electronic the electronic count coding technology, precise control of the injection volume.
4 double metal screw, tripling its service life than conventional general screw.
The main technical parameters:

Public median 24
clamping force 600KN
recommended mold size (600 × 300 × 250) mm
screw diameter Φ75mm / Φ60mm/Φ60mm
aspect ratio 20:01
maximum range 200mm
  66MPa
injection speed 10cm/sec
screw speed 0-200 r.p.m
temperature control the number of segments 4
fan power 6kw
electric power 3 × 10.4kw
motor power 3 × 22kw
fuel tank capacity 3 × 800L
Machine Weight 26t
machine size (11 × 8.1 × 2.35) m
production 180pairs / h
